-45℃ -65℃ -86℃ Vertical ultra-low temperature freezer

  • Description
  • Technical Specifications
  • Competitive Advantage

1.Control system

Adopt independent research and development intelligent control system

4.3-inch color capacitive touch screen, multi-level password management, 7-inch color touch screen above 310L (not included), the refrigeration system is two independent systems, one set of refrigeration system is abnormal, and the other set of refrigeration system

The set value can still be maintained, and the screen visually displays the set value, actual value, ambient temperature, condensation temperature, Beijing time, etc

The system has a screen lock function to prevent irrelevant people from changing parameters

2.Refrigeration system

Adopt original imported ultra-low temperature compressor

All copper pipe design, high uniformity of evaporation pipe around

Single stack refrigeration system, high efficiency and energy saving

Mixed hydrocarbon refrigerant, does not harm the atmospheric ozone layer, more environmentally friendly

3.Safety system products are equipped with high-strength alloy pressing handle, built-in safety lock, and padlock (30L,60L not included)

High strength casters with lock to prevent product displacement caused by uneven ground or vibration

Internet of Things remote monitoring system, no cumbersome networking, scanning code to add products

4.Insulation system

High density vacuum adiabatic foaming technology is adopted.

10cm super thick insulation layer, effectively prevent cold loss.

Application:

This product is used for ultra-low temperature preservation of reagents, drugs, biological samples and products; Used for low temperature test and cold treatment of special materials, electronic devices and mechanical parts; Special ice cream, aquatic products, seafood and tuna and other ultra-low temperature preservation.

Temperature control rangeModelVolumeOverall dimensionInner dimensionNet weightInput powerrefrigerating fluid
-10℃~-45℃DW-45L3030470x490x1120mm270x270x400mm60kg350W(220V,50Hz)Mixed refrigerant
DW-45L6060600x670x1140mm370x410x410mm75kg450W(220V,50Hz)
DW-45L110110770x730x1260mm460x490x510mm105kg460W(220V,50Hz)
DW-45L210220880x730x1480mm570x800x490mm220kg650W(220V,50Hz)
DW-45L310310800x760x1810mm570x485x1140mm190kg690W(220V,50Hz)
DW-45L410410850x930x1950mm550x630x1140mm230kg780W(220V,50Hz)
DW-45L510510875x730x1900mm700x670x1150mm260kg950W(220V,50Hz)
DW-45L610610940x980x1920mm700x680x1260mm280kg1160W(220V,50Hz)
DW-45L7107101160x980x1860mm850x740x1170mm290kg1260W(220V,50Hz)
DW-45L8108101160x980x2030mm850x740x1340mm310kg1350W(220V,50Hz)
DW-45L9409401240x1000x2000mm1000x700x1340mm320kg1420W(220V,50Hz)
-25℃~-65℃DW-65L3030470x490x1120mm270x270x400mm60kg450W(220V,50Hz)
DW-65L6060600x670x1140mm370x410x410mm75kg550W(220V,50Hz)
DW-65L110110770x730x1260mm460x490x510mm105kg560W(220V,50Hz)

DW-65L160160700x700x1580mm460x460x800mm130kg650W(220V,50Hz)
DW-65L210210880x730x1480mm570x800x490mm220kg750W(220V,50Hz)
DW-65L310310800x760x1810mm570x485x1140mm190kg790W(220V,50Hz)
DW-65L410410850x930x1950mm550x630x1140mm230kg880W(220V,50Hz)
DW-65L510510875x730x1900mm700x670x1150mm260kg1050W(220V,50Hz)
DW-65L610610940x980x1920mm700x680x1260mm280kg1260W(220V,50Hz)
DW-65L7107101160x980x1860mm850x740x1170mm290kg1360W(220V,50Hz)
DW-65L8108101160x980x2030mm850x740x1340mm310kg1450W(220V,50Hz)
DW-65L9409401240x1000x2000mm1000x700x1340mm320kg1520W(220V,50Hz)

DW-86L3030470x490x1120mm270x270x400mm60kg550W(220V,50Hz)
DW-86L6060600x670x1140mm370x410x410mm75kg650W(220V,50Hz)
DW-86L110110770x730x1260mm460x490x510mm105kg660W(220V,50Hz)
DW-86L160160700x700x1580mm460x460x800mm130kg750W(220V,50Hz)
DW-86L210210880x730x1480mm570x800x490mm220kg850W(220V,50Hz)
DW-86L310310800x760x1810mm570x485x1140mm190kg890W(220V,50Hz)
DW-86L410410850x930x1950mm550x630x1140mm230kg980W(220V,50Hz)
-40℃~-86℃DW-86L510510875x730x1900mm700x670x1150mm260kg1150W(220V,50Hz)
DW-86L610610940x980x1920mm700x680x1260mm280kg1360W(220V,50Hz)
DW-86L7107101160x980x1860mm850x740x1170mm290kg1460W(220V,50Hz)
DW-86L8108101160x980x2030mm850x740x1340mm310kg1550W(220V,50Hz)
DW-86L9409401240x1000x2000mm1000x700x1340mm320kg1620W(220V,50Hz)

Unique single-stage refrigeration technology and design, strong cooling, fast cooling;

Single stage compression, mixed refrigerant system, double door seal, thick insulation structure, high efficiency and energy saving;

The main components are international well-known brands, multiple alarm functions, copper tube evaporator, to ensure reliable operation and storage of samples or food safety;

Color touch screen control system, accurate temperature control, simple operation;

Curve visual display, data can be traced;

The bottom with self-locking universal wheel design, easy to move freely;

Fluoride-free mixing medium and blowing agent, green and environmental protection.
